Product details Image Sensor 1/2.7″ 5MP PS CMOS (0.9407cm) Minimum Illumination 0.005Lux/F1.6, 0Lux White Light on BodyType Dome Shutter Speed PAL: 1/25~1/100000s NTSC: 1/30~1/100000s Max Aperture F1.6 White Balance Auto/Manual Lens Type Fixed Lens 3.6mm Gain Control (AGC) Auto/Manual DORI Distance 3.6mm: 80m(Detect), 32m(Observe), 16m(Recognize), 8m(Identify) Angle of View 3.6 mm: 109° × 92° × 48° (diagonal × horizontal × vertical) S/N Ratio >65dB Back Light Comp. BLC/ HLC/ DWDR Video Streaming CVI: PAL: 5M@25fps; 4M@25fps; 1080P@25fps; NTSC: 5M@25fps; 4M@30fps; 1080P@30fps; AHD: PAL: 4M@25fps; NTSC: 4M@30fps TVI: PAL: 4M@25fps; NTSC: 4M@30fps CVBS: PAL: 960H; NTSC: 960H Privacy Mask Off/on (8 area, rectangle) Video Output Video output choices of CVI/TVI/AHD/CVBS by one BNC port Audio Input Built-in Mic Illumination Distance Illumination Range of 20 Mtr. Operating Temperature -40°C ~ 55°C; Less than <95% RH (non-condensation) Power Source 12V DC ±30% Power Consumption Max 3.0W (12V DC, White Light on) Weatherproof Standard IP67 Dimension φ97 mm × 86.6 mm Casing Plastic
